Connect Figma

Figma has no built-in Kody OAuth app. Connect with bring-your-own OAuth (recommended) or a personal/plan access token, then call Figma through @kody/figma over the Figma REST API.

Agents use Figma through Kody REST (an OAuth integration or a PAT plus @kody/figma). This is not Figma's allowlisted remote MCP. Do not connect Figma's remote MCP for this path.

What you get

Once connected, you can ask Kody things like:

• "Summarize the Checkout file and list its top-level pages."
• "List comments on this Figma design URL."
• "Render the empty-state frame as a PNG."

Exact capabilities depend on the OAuth scopes or token permissions you grant.

▶Play Give your agent Figma access with Kody

Before you start

• You need a Figma account and access to the developer apps console (Lane A) or personal/plan tokens (Lane B).
• All REST calls go to api.figma.com. Approve that host when you save the integration or secret.
• Fork @kody/figma after credentials exist; do not treat the live listing package storage as yours.

Lane A: BYO OAuth (recommended)

1. Create an OAuth app at www.figma.com/developers/apps.
2. Set the redirect URI exactly to https://kody.codes/connect/oauth (a self-hosted deployment registers its own origin plus /connect/oauth).
3. Enable exactly these scopes on the Figma OAuth app: current_user:read, file_content:read, file_metadata:read, file_comments:read, file_comments:write, file_versions:read, library_content:read, library_assets:read, folders:read. Figma returns HTTP 400 Invalid scopes when authorize asks for a scope the app does not offer, a deprecated scope, or an enterprise-only extra.
4. Copy the client ID and client secret from the Figma app page.

Connect to Kody

Open the prefilled connect URL while signed in to Kody:

https://kody.codes/connect/oauth?provider=figma&authorizeUrl=https%3A%2F%2Fwww.figma.com%2Foauth&tokenUrl=https%3A%2F%2Fapi.figma.com%2Fv1%2Foauth%2Ftoken&apiBaseUrl=https%3A%2F%2Fapi.figma.com&scopes=current_user%3Aread%20file_content%3Aread%20file_metadata%3Aread%20file_comments%3Aread%20file_comments%3Awrite%20file_versions%3Aread%20library_content%3Aread%20library_assets%3Aread%20folders%3Aread&flow=confidential&pkce=true&allowedHosts=api.figma.com&dashboardUrl=https%3A%2F%2Fwww.figma.com%2Fdevelopers%2Fapps

Decoded: authorize URL https://www.figma.com/oauth, token URL https://api.figma.com/v1/oauth/token, apiBaseUrl=https://api.figma.com, scopes space-separated as listed above, flow=confidential, pkce=true, and allowedHosts=api.figma.com. Paste the client ID and client secret into the setup form (never into chat), then authorize. Approve host api.figma.com if the form still asks.

Reconnect later with https://kody.codes/connect/oauth?provider=figma.

To connect a second account, change provider (for example provider=figma-work) and pass integrationName: 'figma-work' on package calls.

See the OAuth guide for query parameters, confidential exchange plus PKCE, and reconnect behavior.

Lane B: personal or plan access token

1. Create a personal access token from Figma Settings → Security, or a plan token at www.figma.com/developers/tokens (PAT docs).
2. Save it through the account secrets page. Never paste the token into chat:

https://kody.codes/account/secrets/new?name=figmaPat&description=Figma%20personal%20or%20plan%20access%20token&allowedHosts=api.figma.com&scope=user

Approve api.figma.com on the same page after saving. The name figmaPat is what @kody/figma reads by default.

For a second account or token, use a distinct secret name such as figmaPat-work and pass secretName: 'figmaPat-work' (or account: 'work').

Use the official package and verify

Credentials alone are not the finish. Fork @kody/figma so your automations call maintained helpers over Figma REST:

1. Search for @kody/figma (or open the listing) and communityFork it into your scope (or click Install).
2. Check the fork's README Required setup: Lane A expects an OAuth integration named figma; Lane B expects secret figmaPat. Both need host api.figma.com.
3. Verify from execute (adjust the import to your fork):

import smokeTest from 'kody:@<your-username>/figma/smoke-test'

export default async function main() {
	return smokeTest()
}

A successful live response looks like { ok: true, live: true, … } without returning account PII. Without credentials, smoke-test still returns setup URLs so the package stays forkable before anyone connects.

Optional OAuth-only probe with the raw runtime helper:

import { createAuthenticatedFetch } from 'kody:runtime'

export default async function main() {
	const figmaFetch = await createAuthenticatedFetch('figma')
	const response = await figmaFetch('https://api.figma.com/v1/me')
	if (!response.ok) {
		throw new Error(
			`Figma smoke test failed: ${response.status} ${await response.text()}`,
		)
	}
	const me = (await response.json()) as { id?: string; handle?: string }
	return { id: me.id, handle: me.handle }
}

Scopes

Enable exactly those scopes on the Figma OAuth app when using Lane A. Narrower grants work for a subset of helpers; insufficient-scope errors name the missing scope and the next setup URL.

Troubleshooting

• HTTP 400 Invalid scopes on authorize: the Figma OAuth app is missing a scope from the connect URL, still offers a deprecated scope, or the request includes an enterprise-only scope. Align the app and reconnect.
• redirect_uri mismatch: the registered redirect must be exactly https://kody.codes/connect/oauth.
• Host approval failures or blocked fetches: approve api.figma.com on the integration or figmaPat secret. REST is host-locked to that API host.
• 401 / 403 after a successful connect: reconnect (/connect/oauth?provider=figma) or rotate figmaPat; confirm the granted scopes cover the helper you called.
• Looking for Figma's remote MCP: that is a different path. This guide and @kody/figma use Kody REST only.
